Via
Surface Mounted Wall Mount Luminary
Optics
Reflector & Glass
Luminous Flux
1260 lm / 630 lm
Consumption Power
14 W / 7 W
Light Color Temperature (CCT)
2700K/3000K/4000K/6500K
220V 240V
IP 65
70K
Product Features
- Luminaire Group Wall Mount
- Mounting Type Surface Mounted
- Housing DKP Sheet
- Optics Reflector & Glass
- Light Source LED
- Electrical Protection Class CLASS II
- IP 65
- Operating Temperature -20°C / +40°C
- Luminous Flux 1260 lm / 630 lm
- Consumption Power 14 W / 7 W
- Luminaire Efficiency 90 lm/W
- Color Rendering (CRI) >80
- Light Color Temperature (CCT) 2700K/3000K/4000K/6500K
- Color Tolerance < 3 SDCM
- Driver Type On/Off
- Driver Brand Tridonic
- LED Brand Samsung
- Input Voltage / Frequency 220-240 V AC 50/60 Hz
- Power Factor >0.9
- Surge 1kV
- THD (AKIM) >%20
- LED life >70.000 hours
- Option On-Off / Dali / 1-10V
Optics
Dimensions
Product Variations
| SKU | Product Code | Power (W) | Luminous Flux (LM) | CCT (K) | Optics | Dimensions (mm) | Datasheet |
|---|---|---|---|---|---|---|---|
| VIA 006 023 007D 8040 10 30 CA 65 00 | 7 | 630 | 4000 | 30° Reflector | Ø60x230mm |
|
|
| VIA 006 023 007D 8040 10 40 CA 65 00 | 7 | 630 | 4000 | 40° Reflector | Ø60x230mm |
|
|
| 18100021 | VIA 006 023 014D 8040 10 15 CA 65 00 | 14 | 1260 | 4000 | 15° Reflector | Ø60x230mm |
|
| 18100057 | VIA 006 023 014D 8040 10 30 CA 65 00 | 14 | 1260 | 4000 | 30° Reflector | Ø60x230mm |
|
| 18100093 | VIA 006 023 014D 8040 10 40 CA 65 00 | 14 | 1260 | 4000 | 40° Reflector | Ø60x230mm |
|
Download
