Concreto C1/C2
Pendant Wood & Concrete Products Luminary
Optics
LED Bulb
Luminous Flux
3380 lm
Consumption Power
25 W
Light Color Temperature (CCT)
2700K/3000K/4000K/6500K
220V 240V
IP 20
IK 02
20K
Colour Options
RAL 7035
Product Features
- Luminaire Group Wood & Concrete Products
- Mounting Type Pendant
- Luminary Color RAL 7035 -
- Housing Concrete and Wood
- Optics LED Bulb
- Light Source LED
- Electrical Protection Class CLASS II
- IP 20
- IK 02
- Operating Temperature -20°C / +40°C
- Luminous Flux 3380 lm
- Consumption Power 25 W
- Luminaire Efficiency 130 lm/W
- Color Rendering (CRI) >80
- Light Color Temperature (CCT) 2700K/3000K/4000K/6500K
- Color Tolerance < 3 SDCM
- Driver Type On/Off
- Driver Brand Tridonic
- LED Brand Samsung
- Input Voltage / Frequency 220-240 V AC 50/60 Hz
- Power Factor >0.9
- Surge 1kV
- THD (AKIM) >%20
- LED life >20.000 hours
Dimensions
Product Variations
| Product Code | Power (W) | Luminous Flux (LM) | CCT (K) | Optics | Dimensions (mm) | Datasheet |
|---|---|---|---|---|---|---|
| CRO 090 019 025P 8040 10 GU10 20 00 C1 | 25 | 3380 | 4000 | 100° GU10 | Ø130x186 |
|
| CRO 163 036 025P 8040 10 GU10 20 00 C2 | 25 | 3380 | 4000 | 100° GU11 | Ø170x355 |
|
Download
